CONVEYOR BELT 14'x 12" LINKIT 300


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

Daily: $155.00

Weekly: $619.00

Quantity: for a period of
day(s) week(s)

Additional Information

DIMENSIONS - 11” H x 174” L x 24” W
WEIGHT - 278 lbs.
RATED CAPACITY - 60 metric Tph
RUBBER BELT - Vulcanized 2-ply poly reinforced w/ chevron
BELT CAPACITY - 330 lbs.
BELT SPEED(Forward / Reverse) - 92 ft/min (fast), 65 ft/min (slow)
MAXIMUM ANGLE - 35 degrees
TEMPERATURE RATING - Motor: -13° F - Belt: 15° F (min) / 185° F (max)
DRUM MOTOR - Rulmeca 0.55kW (1/2HP)
INVERTER - IMO Jaguar CUB5A-6J, 110v 1-phase input / 220v 3-phase output
AMP DRAW - 1.2 run / 5.0 peak
NOISE EMISSIONS - >75 dB
MAX 4 CONVEYORS ON 1 115V CIRCUIT
