MANLIFTS

MANLIFT 60'- 65' COMBUSTION


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

Daily: $430.00

Weekly: $1,248.00

Quantity: for a period of
day(s) week(s)

Additional Information

RATES are based on 8 hrs/day, 40 hrs/week, 160 hrs/4weeks

Range Of Motion Z-62/40
Measurements US Metric
Working height maximum* 67 ft 11 in 20.87 m
Platform height maximum 61 ft 11 in 18.87 m
Horizontal reach maximum 40 ft 5 in 12.42 m
Up and over clearance maximum 25 ft 7 in 7.8 m
Height - stowed 8 ft 4 in 2.54 m
Length - stowed 30 ft 3 in 9.25 m
Length - transport (jib tucked under) 24 ft 10.5 in 7.58 m
Width 8 ft 2 in 2.49 m
Wheelbase 8 ft 2 in 2.49 m
Ground clearance - center 1 ft 4 in 41 cm
Weight: 24,000lb

JLG 600AJ Articulated Z-BOOM DIESEL
Platform Capacity - Unrestricted: 230 kg / 507 lb
Platform Height: 18.46 m / 61 ft
Horizontal Jib Rotation 0 Degrees
Horizontal Outreach 12.10 m / 40 ft
Platform Height 18.46 m / 61 ft
Up and Over Height 8.09 m / 27 ft
Vertical Jib Rotation 130 Degrees

GENIE S-65 STRAIGHT BOOM DIESEL
Working Height* 71 ft (21.80 m)
Platform Height 65 ft (19.80 m)
Horizontal Reach 56 ft 2 in (17.10 m)
Lift Capacity 500 lbs (227 kg)

JLG 660SJ Specifications
Performance:
Platform Height (max.) 20.31m 66'
Working Height 22.31m 73'
Platform Rotation Angle 180°
Jib Raise Angle 70°
Jib Lower Angle 60°
Jib Articulation Range 130°
Maximum Horizontal Outreach 17.3m 56'
Lift Time 46-60 sec
Lower Time 33-43 sec
Platform Capacity 230kg 507LB
Slewing Angle 360°
Continuous Slew Yes
Dimensions:
Stowed Length 10.21m 33.4'
Stowed Height 2.56m 8.2'
Overall Width 2.42m 8'
Wheelbase 2.48m 8.2'
Ground Clearance 0.30m 1'
Platform Width 2.44m 8'
Platform Length 0.91m
Overall Jib Length 1.83m 3'
Tailswing 1.14m 3'9"
Power Source Diesel

Also check the following item(s) related to the above:

SAFETY HARNESS

* Prices are subject to change.

* Please call us with any questions about our manlift 60 foot 65 foot combustion in Whistler BC, serving Squamish, Pemberton, and the Sea-to-Sky Corridor.
